$4,945
SPECIFICATIONS
With a powerful DC motor, the On-A-Roll® Lifter Power Universal Hi-Rise eliminates the manual labor of lifting and lowering rolls, reducing roll changeover time. The Foster On-A-Roll® Lifter Power Universal Hi-Rise enables users to effortlessly lift rolls as heavy as 300 kg (660 lbs.) and as wide as 400 cm (13’). The flat roll loading tray fits most laminators and easily reaches laminator’s upper loading shaft height. Two adjustable roll wedges for positioning rolls on the tray are removable for loading and unloading
| Roll Weight Capacity | 660 lbs (300 kg) |
| Lift Height | 54” H (135 cm) |
| Max. Roll Width | 13’ (400 cm |
| Max. Roll Diameter | 15.75” (40 cm) |
| Overall Media Lifter Dimensions (W x D x H) | 47.25” W x 35.5” D x 68” H (120 x 90.3 x 173cm) |
| Media Lifter Weight | 271 lbs (123 kg) |
| Bottom Fork Clearance | 3.25” (8.25 cm) |
| Front Swivel Castors | 2” (5 cm) |
| Rear Swivel Castors | 5” (12.7 cm) |
| Electric | 12V/60AH DC motor USA (220V/50HX DC motor Europe) |
| Battery | Maintenance-free lead acid battery |
| Charger | Built-in 110V AC charger USA (Built-in 220V AC charger Europe) |
